Gallery: C152AP - SCREEN CHANNEL

Overview

Composition: 1 × C152AP Two Way Cinema Screen Speaker

Engineered to command expansive PLF auditoriums and commercial screens up to 80 feet, the C152AP represents the pinnacle of versatility and power within our Pro Cinema range. This high-performance 2-way system—available in both bi-amplified and passive configurations—utilises world-class Lavoce drivers from Italy, pairing a formidable dual 15-inch low-frequency section with a high-precision 2-inch exit compression driver. Meticulously optimised for Dolby Atmos, Dolby 7.1, and DTS:X installations, it delivers an ultra-dynamic, seamless auditory experience that brings breathtaking clarity and effortless scale to massive cinema environments.

Features

Dolby Surround 7.1 Ready
Dolby Surround 7.1 Ready
Dolby Atmos Ready
Dolby Atmos Ready
DTS:X Ready
DTS:X Ready
Powered By Lavoce Italiana
Powered By Lavoce Italiana
2 Way Bi-Amp System
2 Way Bi-Amp System
Cinema Length: Up to 80 ft
Cinema Length: Up to 80 ft

Applications

Cinemas
Multiplexes
Megaplexes
PLF Screens

Warranty

Product Warranty

3 Years

Terms & Conditions Apply

Specifications

SYSTEM
Model
C152AP
Configuration
Two Way Bi-Amplified / Passive Speaker System
Frequency Range
50 Hz to 20 KHz
Sensitivity LF
103 dB
Sensitivity HF
108 dB
Maximum SPL
138 dB
Nominal Impedance
Bi-amp: LF - 4 Ohms & HF - 8 Ohms & Passive: 8 Ohms
Connectors
4 Pin Barrier Terminal Block Connector
POWER
Power LF (AES)
800 Watts
Power MHF (AES)
200 Watts
Recommended Amp Power LF
1200 Watts (RMS) at 4 Ohms
Recommended Amp Power HF
500 Watts (RMS) at 8 Ohms
Recommended Amplifier
DB Sound DB1200
DRIVERS
Low Frequency Driver
Dual 15 Inch (380 mm) paper cone driver with 3 Inch (75 mm) Voice Coil
High Frequency Driver
Single 1 Inch (50 mm) Compression Driver with 3 Inch (75 mm) titanium diaphragm Voice Coil
Horn
90° × 40° for HF with Tilt & Swivel Bracket
PHYSICAL
Enclosure Material
18 mm Birch Plywood
Dimensions (H × W × D)
1525 mm × 500 mm × 400 mm
Weight
58.50 Kgs
