Gallery: KS904 - MULTICHANNEL POWER AMPLIFIER

Overview

Composition: 1 × KS904 Multichannel Power Amplifier

Representing a pinnacle of professional audio engineering, this high-output series of 4-channel power amplifiers is meticulously crafted to meet the rigorous demands of modern sound reinforcement. The Sider Fusion KS series comprises three distinct models engineered to scale with your power requirements: the KS904 delivers a substantial 4 X 900W, the KS1204 offers an impressive 4 X 1200W, and the flagship KS2004 provides a formidable 4 X 2000W, all sustained into a stable 4 Ohm load. Central to their exceptional performance is advanced Class H+ circuitry, a sophisticated design that maximises sonic fidelity and dynamic impact whilst minimising energy consumption and operational heat. Housed within a space-saving 2U chassis, these amplifiers facilitate seamless integration into diverse rack configurations, making them equally suited for intimate setups and expansive auditoriums. To ensure absolute longevity and consistent audio delivery under challenging conditions, the series features a comprehensive protection suite including DC Protect, Short Circuit Protection, Overheat Protection, and Soft Start Operation. Complete with flexible connectivity—comprising XLR balanced inputs, Neutrik NL4 speakON sockets, and traditional binding posts—this versatile multi-channel lineup stands as the ideal choice for demanding applications in commercial cinemas, premium home theatres, and high-performance installed sound environments.

Features

2U Chassis Design
2U Chassis Design
Class H+ Design
Class H+ Design
4 CH Amplifier
4 CH Amplifier
speakON Outputs
speakON Outputs

Applications

A/V Portable
Music Reproduction
Pro Audio Installs
Commercial Cinema Applications
Installed Sound Reinforcement

Warranty

Product Warranty

2 Years

Terms & Conditions Apply

Specifications

SYSTEM
Model
KS904
Frequency Response At 1 Watt into 8 Ohm
±0.4dB, 10 Hz – 20KHz
Input / Output Connectors
XLR Balanced / 4 Neutrik NL4 Sockets & 4 Binding Post
Input Impedance
10 KΩ Balanced / 20 KΩ Unbalanced
Circuit Type
Class H
Indicators
Signal, Protect, Clip, Limiter
POWER
Output 8 Ohms 1KHz 0.1% THD Stereo Mode
4 x 600W
Output 4 Ohms 1KHz 0.1% THD Stereo Mode
4 x 900W
Output 8 Ohms 1KHz 0.1% THD Bridge Mode
2 x 1800W
Output 4 Ohms 1KHz 0.1% THD Bridge Mode
2 x 2400W
Fuse
F-20A
S/N Rate
> 100 dB
Slew Rate
> 28 v/μs
Damping factor
>3000 (8 Ohm) 10Hz – 100Hz
Power Supply
220V 50/60Hz
Input Sensitivity
0.775V,1.0V,1.4V
THD+N
≤0.5% @ 8Ω 1kHz
Crosstalk at Rated Output 8 Ohms 1kHz
>70dB
PHYSICAL
Dimensions (H x W x D)
90 x 483 x 492mm
Weight
27.25 Kgs
